PROPEL ADV PRO DA 2027

R159,990.00 RRP

Features

Features

Hang with the fast group, go for the sprint, cheat the wind on a solo ride. The new Propel Advanced Pro is now lighter, smoother and more efficient, delivering higher speeds to help you maximize every effort.

Key Performance Factors

Instant Speed

In the moments when explosive speed matters most—launching an attack, chasing a break, or sprinting for the finish line—the new Propel Advanced Pro is quicker and more dynamic than ever. The frameset is lighter than the previous generation with greater torsional stiffness and pedaling stiffness—so you feel instantaneous reaction when you make your move.

Sustained Speed

A reengineered frameset and integrated components combine for a smoother ride when you’re rolling in the group or piling up training miles. The Vector seatpost offers greater compliance compared to the previous generation, while the fork and integrated cockpit absorb bumps and vibrations up front. And additional tire clearance allows for high-volume tires up to 32mm, further smoothing out the ride to help you maintain higher speeds with less fatigue.

Top-End Speed

The frameset, cockpit, wheels and tires form a unified system that lowers total resistance when you’re pushing high speeds. The AeroSystem frame and integrated cockpit minimize drag, while the aero WheelSystem and tires reduce rolling resistance. That means more speed for taking pulls, rolling off the front, or driving the pace across flats and over climbs.

Specification

Specification

Specs
  • Sizes
    XS, S, M, M/L, L, XL
  • Colors
    Supernova Grey
  • Frame
    Advanced-grade Composite, 12x142mm thru-axle, disc
  • Fork
    Advanced SL-grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
  • Handlebar
    Giant Contact SLR 0 Aero Integrated XS:380/360mm, S:380/360mm, M:400/370mm, M/L:400/370mm, L:420/390mm, XL:420/390mm
  • Grips
    Stratus Lite 2.0
  • Stem
    Giant Contact SLR 0 Aero Integrated XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
  • Seatpost
    Giant Vector, composite, -5/+15mm offset
  • Saddle
    Giant Fleet SL
  • Shifters
    Shimano Dura-Ace Di2 ST-R9270
  • Front Derailleur
    Shimano Dura-Ace Di2 FD-R9250
  • Rear Derailleur
    Shimano Dura-Ace Di2 RD-R9250
  • Brakes
    Shimano Dura-Ace Di2 hydraulic, Shimano RT-CL900 rotors [F]160mm, [R]140mm
  • Brake Levers
    Shimano Dura-Ace Di2
  • Chain
    Shimano Dura-Ace CN-M9100
  • Crankset
    Shimano Dura-Ace, 36/52 XS:165mm, S:165mm, M:170mm, M/L:170mm, L:172.5mm, XL:172.5mm
  • Bottom Bracket
    Shimano, press fit
  • Rims
    Giant SLR 0 50 Carbon WheelSystem, [F]50mm, [R]50mm
  • Hubs
    [F] Giant Aero Hub, CenterLock [R] Giant Aero Hub, 40T ratchet driver, CenterLock 12mm thru-axle
  • Spokes
    Aero Carbon
  • Tires
    CADEX Aero, tubeless, 700x28c (28mm), folding
  • Extras
    computer mount, water bottle cages, tubeless prepared, 32mm max tire size
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.


*All specifications and prices listed are subject to change without notice.
Actual weight may vary due to manufacturing tolerances, color variations, frame size and variability in production components.

Geometry

Geometry

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.



  • XS
      157 cm to 169 cm
  • S
      165 cm to 175 cm
  • M
      171 cm to 181 cm
  • M/L
      177 cm to 187 cm
  • L
      183 cm to 193 cm
  • XL
      189 cm to 199 cm
bike diagram with measurements referenced in table that follows



  XS S M M/L L XL
A Seat Tube Length (mm) 484 505 528.5 554 576 595
B Seat Tube Angle (degrees) 74.5° 74.0° 73.5° 73.0° 73.0° 72.5°
C Top Tube Length (mm) 520 535 550 565 580 600
D Head Tube Length (mm) 115 127 145 165 185 200
E Head Tube Angle (degrees) 71.5° 72.5° 73.0° 73.0° 73.0° 73.0°
F Fork Rake (mm) 45 45 45 45 45 45
G Trail (mm) 67.8 61.4 58.3 58.3 58.3 58.3
H Wheelbase (mm) 971 973 980 990 1006 1020
I Chain Stay Length (mm) 405 405 405 405 405 405
J Bottom Bracket Drop (mm) 72 72 69.5 69.5 67 67
K Stack (mm) 515 530 546 565 582 596
L Reach (mm) 377 383 388 392 402 412
M Stand Over Height (mm) 746 764 787 808 832 847
N Handlebar Width (mm) 380 380 400 400 420 420
O Stem Length (mm) 80 90 100 110 110 120
P Crank Length (mm) 165 165 170 170 172.5 172.5
Q Wheel Size 700C 700C 700C 700C 700C 700C
