PIQUE ADV 29ER 2 2025

R99,990.00 RRP
Clear All

Features

Features


Cross-country is evolving beyond fast-and-flowy to fast-and-everything—technical terrain, all-day epics, and stage races. The new Pique Advanced 29 is …ready for it. Reengineered for greater efficiency and control, this XC queen was built to slay switchbacks, rock gardens, and yesterday’s PRs.

Key Performance Factors

EFFICIENCY IS SPEED

Now 297g lighter*, the Advanced-grade composite frameset also features greater stiffness for efficient power transfer, a massive advantage on climbs and at speed. New FlexPoint Pro suspension minimizes weight by minimizing parts. And a shorter chainstay offers greater agility for maneuvering switchbacks, and snappy acceleration for seizing every overtake opportunity.

CONTROL IS POWER

With its patented, linkage-driven, single-pivot design, the new FlexPoint Pro suspension delivers 115mm of smooth, active rear-wheel travel, so you can maximize power and traction over ever-changing and uber-challenging terrain. Combined with a slacker head tube angle and 120mm of front suspension, this setup ensures you're equipped to dominate technical descents.

STABILITY IS MASTERY

Roll over just about anything on 29-inch wheels designed for stability and efficiency. Updated geometry provides a longer reach, putting you in a lower and more aggressive body position. A steeper seat tube angle increases pedaling efficiency on even the steepest climbs. And the modified cockpit includes a 35mm composite handlebar and alloy stem for steering precision.

Specification

Specification


Specs
  • Sizes
    XS, S, M, L
  • Colors
    Golden Haze/Carbon/Chrome
  • Frame
    Advanced-grade composite front and rear triangles, 115mm FlexPoint Pro Suspension, 12x148mm thru-axle
  • Fork
    Fox 34 Float SC Performance Remote, 120mm, GRIP damper, Boost 15x110 KaBolt, 44mm offset, 3 position remote lockout
  • Shock
    Fox Float SL Performance Elite, 165x45, custom tuned for Liv, recommended sag 25%
  • Handlebar
    Giant Contact XC Flat, 760x35mm
  • Grips
    Liv XC Pro, 32mm
  • Stem
    Giant Contact SL XC, alloy, 35mm XS: 60mm, S: 60mm, M: 70mm, L: 70mm
  • Seatpost
    Giant Contact Switch AT dropper, remote XS: 110-140mm travel / 30.9 x 395mm S: 110-140mm travel / 30.9 x 395mm M: 140-170mm travel / 30.9 x 470mm L: 140-170mm travel / 30.9 x 470mm
  • Saddle
    Liv Grit SL
  • Shifters
    Shimano Deore XT SL-M8100, 1x12
  • Front Derailleur
    N/A
  • Rear Derailleur
    Shimano Deore XT RD-M8100, Shadow+
  • Brakes
    Shimano SLX BR-M7100, hydraulic, Shimano RT-56 rotors [F]180mm, [R]160mm
  • Brake Levers
    Shimano Deore BL-M7100
  • Cassette
    Shimano XT, M8100, 10x51
  • Chain
    KMC X-12
  • Crankset
    Shimano XT M8120, 30t, 55mm chainlineXS: 165mm, S: 170mm, M: 170mm, L: 175mm
  • Bottom Bracket
    Shimano, press fit
  • Rims
    Giant XCR 2 29 Carbon WheelSystem
  • Hubs
    [F] Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt
  • Spokes
    Sapim
  • Tires
    Maxxis Aspen 29x2.4, foldable, 120tpi, TLR, EXO, tubeless
  • Extras
    tubeless prepared, custom Giant MRP chain guide, 3M clear foil down tube protector, max tire size 2.4-inch, max chainring size 34t
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Download PDF

*All specifications and prices listed are subject to change without notice.
Actual weight may vary due to manufacturing tolerances, color variations, frame size and variability in production components.

Geometry

Geometry


Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.



  • XS
      150 cm to 163 cm
  • S
      158 cm to 169 cm
  • M
      164 cm to 175 cm
  • L
      170 cm to 181 cm
bike diagram with measurements referenced in table that follows



    XS S M L
A Seat Tube Length (mm) 380 410 440 470
A1 Seat Post Insertion Depth (mm) 203 233 263 293
B Seat Tube Angle (degrees) 76.0° 76.0° 76.0° 76.0°
C Top Tube Length (mm) 555 570 585 600
D Head Tube Length (mm) 90 95 105 115
E Head Tube Angle (degrees) 67.0° 67.0° 67.0° 67.0°
F Fork Rake (mm) 44 44 44 44
G Trail (mm) 112.2 112.2 112.2 112.2
H Wheelbase (mm) 1121 1137 1154 1170
I Chain Stay Length (mm) 435 435 435 435
J Bottom Bracket Drop (mm) 45 45 45 45
K Stack (mm) 599 603 612 622
L Reach (mm) 406 420 432 445
M Stand Over Height (mm) 748 767 770 791
N Handlebar Width (mm) 760 760 760 760
O Stem Length (mm) 60 60 70 70
P Crank Length (mm) 165 170 170 175
Q Wheel Size 29" 29" 29" 29"
