PROPEL ADV 2 2025

R63,019.00 RRP
Clear All

Features

Features


Maximize your watts during sprints, breakaways and solo attacks. This aero road machine is built to give you a real advantage against the wind. Because small gains lead to big wins.

Key Performance Factors

Integrated aerodynamics

AeroSystem Shaping, a result of CFD analysis and dynamic wind-tunnel testing, optimizes aerodynamic performance at every yaw angle. The truncated ellipse airfoil tube shapes and all-new Contact SL Aero cockpit produce superior aero performance.

Easier adjustability

All-new cable routing through the stem and head tube makes it quicker and easier to adjust or change cockpit components and fine-tune performance and riding position.

Race-winning efficiency

Advanced-grade composite frame and hybrid alloy/composite fork deliver optimal stiffness and weight savings. The result is an even greater stiffness-to-weight advantage.

Specification

Specification


Specs
  • Sizes
    XS, S, M, M/L, L, XL
  • Colors
    Carbon/Chrome, Mars Dust
  • Frame
    Advanced-Grade Composite, 12x142mm thru-axle, disc
  • Fork
    Advanced-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
  • Shock
    N/A
  • Handlebar
    Giant Contact SL Aero XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
  • Grips
    Stratus Lite 2.0
  • Stem
    Giant Contact SL Aero XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
  • Seatpost
    Giant Vector, composite, -5/+15mm offset
  • Saddle
    Giant Fleet SL
  • Shifters
    Shimano 105
  • Front Derailleur
    Shimano 105
  • Rear Derailleur
    Shimano 105
  • Brakes
    Shimano 105 hydraulic, Giant MPH rotors [F]160mm, [R]140mm
  • Brake Levers
    Shimano 105 hydraulic
  • Cassette
    Shimano 105, 12-speed, 11x34
  • Chain
    KMC X12L-1
  • Crankset
    Shimano 105, 36/52 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
  • Bottom Bracket
    Shimano, press fit
  • Rims
    Giant P-A2 Disc, alloy
  • Hubs
    Giant P-A2 Disc, 12mm thru-axle
  • Spokes
    Sapim
  • Tires
    Giant Gavia Course 1, tubeless,700x25c (28mm), folding
  • Extras
    computer mount, water bottle cages, tubeless prepared, 32mm max tire size
  • Max Tire Clearance
    32mm
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Download PDF

All specifications listed are subject to change without notice.

Geometry

Geometry


Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

.


  • XS
      157 cm to 169 cm
  • S
      165 cm to 175 cm
  • M
      171 cm to 181 cm
  • ML
      177 cm to 187 cm
  • L
      183 cm to 193 cm
  • XL
      189 cm to 199 cm
bike diagram with measurements referenced in table that follows
    XS S M ML L XL
A Seat Tube Length (mm) 465 500 520 545 575 595
B Seat Tube Angle (degrees) 74.5° 74.0° 73.5° 73.0° 73.0° 72.5°
C Top Tube Length (mm) 520 535 550 565 580 600
D Head Tube Length (mm) 120 130 145 165 185 200
E Head Tube Angle (degrees) 71.0° 72.3° 73.0° 73.0° 73.0° 73.0°
F Fork Rake (mm) 45 45 45 45 45 45
G Trail (mm) 70.5 62.5 57.8 57.8 57.8 57.8
H Wheelbase (mm) 976 977 980 991 1006 1020
I Chain Stay Length (mm) 405 405 405 405 405 405
J Bottom Bracket Drop (mm) 72 70 70 67 67 67
K Stack (mm) 517 528 545 562 581 596
L Reach (mm) 376 383 388 393 402 412
M Stand Over Height (mm) 722 753 770 794 821 834
N Handlebar Width (mm) 400 400 420 420 440 440
O Stem Length (mm) 80 90 100 110 110 120
P Crank Length (mm) 170 170 172.5 172.5 175 175
Q Wheel Size 700C 700C 700C 700C 700C 700C
