1135001100 GIANT FAITH 24 RAW ALUMINUM

Item Code: FA-I4O-G5

R50,990.00 RRP

Features

Features


Small but mighty, this highly capable new trail bike is made for little rippers with big ambitions. With a lightweight alloy frame, 24-inch wheels, and youth-tuned suspension, it balances efficient climbing, loads of traction, and confident handling to help young riders take it to the next level.

Key Performance Factors

YOUTH-TUNED SUSPENSION

FlexPoint rear suspension with a Crest FloTrac Lite shock delivers 130mm of smooth travel tuned specifically for lighter weight riders. Up front, the 140mm Crest TR Elite fork handles rocks, roots and ruts. Front and rear suspension both have minimal activating force, giving young riders smooth control and confidence on technical trails.

AGILE AND EFFICIENT

An ALUXX SL aluminum frameset with youth-specific trail geometry is combined with quality lightweight components to minimize weight and help young riders tackle challenging terrain. A new 24-inch TRA WheelSystem borrows key technologies from the proven adult TRA WheelSystem for improved climbing capabilities and quicker acceleration.

OFF-ROAD CONTROL

Giant TRA WheelSystem features WideGuard technology, resulting in lighter, stronger rims so riders can run lower tire pressures for better traction without the risk of tire punctures or rim damage. The youth-specific 24-inch wheels help smaller riders maneuver and tackle technical trails, while a dropper seatpost makes it easy to optimize riding position while climbing or descending.

Specification

Specification


Specs
  • Colors
    Raw Aluminum
  • Frame
    ALUXX SL-Grade Aluminum front and rear triangles, 12x148mm thru-axle, 130mm FlexPoint suspension
  • Fork
    Crest TR Elite Lite, FloTune Lite Damper, 140mm
  • Shock
    Crest FloTrac Lite, 165/45mm, trunnion mount
  • Handlebar
    Giant Contact TR, 20mm rise, AL6061 aluminum, 680mm
  • Grips
    Giant small-hand
  • Stem
    Giant Contact, 8 degrees, 40mm
  • Seatpost
    Contact Switch AT Lite, 100mm
  • Saddle
    Selle Royal Vivo Jr
  • Pedals
    Giant Pinner Lite
  • Shifters
    MicroSHIFT Advent X Trail trigger shifter SL-M9505-R (with nanowire)
  • Front Derailleur
    N/A
  • Rear Derailleur
    Microshift Advent X RD-M6205AM
  • Brakes
    Tektro [F]180mm, [R]160mm
  • Brake Levers
    Tektro HD-J285
  • Cassette
    Microshift Advent X G-Series 10-speed, 11x48
  • Chain
    KMC X10 with missing link
  • Crankset
    ProWheel Charm, 30t, 140mm
  • Bottom Bracket
    Press Fit
  • Rims
    Giant TRA WheelSystem, alloy, hollow rim wall construction, hookless, 30mm inner width, 40mm outer width, 21mm height, Wide Guard Technology [F] 24” [R] 24"
  • Hubs
    [F] Giant alloy, DBL, six-bolt [R] TRA HE, DBL, 72t pawl driver, 6 bolt
  • Spokes
    Sapim Laser
  • Tires
    [F] Maxxis Minion DHF, 24x2.5, 60 TPI, folding,[R] Maxxis Minion DHR II, 24x2.4, 60 TPI, folding
  • Extras
    Giant 1x chain guide
  • Weight
    12.79kg (28lb 04oz) - Size (24) w/ pedals

*All specifications and prices listed are subject to change without notice.
Actual weight may vary due to manufacturing tolerances, color variations, frame size and variability in production components.

Geometry

Geometry


Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.



  • One Size
      130 cm  to 150 cm
bike diagram with measurements referenced in table that follows



    One Size
A Seat Tube Length (mm) 320
B Seat Tube Angle (degrees) 77.0°
C Top Tube Length (mm) 500
D Head Tube Length (mm) 105
E Head Tube Angle (degrees) 64.5°
F Fork Rake (mm) 30
G Trail (mm) 119.2
H Wheelbase (mm) 1054.1
I Chain Stay Length (mm) 390
J Bottom Bracket Drop (mm)
K Stack (mm) 534.6
L Reach (mm) 376.6
M Stand Over Height (mm) 641
N Handlebar Width (mm) 680
O Stem Length (mm) 40
P Crank Length (mm) 140
Q Wheel Size 24"
