STANCE E+ 2 LTD 2025

- TO BE ANNOUNCED
Clear All

Features

Features


How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

Energypak 625 / SyncDrive Sport


  • Range
  • Extreme: 60 km 37 miles
  • Good: 110 km 68 miles
  • Ideal: 190 km 118 miles

Specification

Specification


Specs
  • Motor
    SyncDrive Sport 2, 75Nm, powered by Yamaha
  • Controller
    RideControl Dash
  • Display
    RideControl Dash, full colour LCD screen
  • Battery
    EnergyPak Smart 625 EnergyPak Plus 250Wh range extender compatible
  • Sizes
    S, M, L, XL
  • Colours
    Space Grey
  • Frame
    ALUXX SL-grade aluminium, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset
  • Fork
    SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
  • Shock
    SR Suntour Raidon R, 190x45mm, custom tuned
  • Handlebar
    Giant Connect TR Riser
  • Grips
    Giant Tactal single lock-on
  • Stem
    Giant Contact
  • Seatpost
    Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
  • Saddle
    Giant Sport
  • Pedals
    Platform
  • Shifters
    Shimano Deore LinkGlide
  • Front Derailleur
    MRP HD2 co-moulded chain guide
  • Rear Derailleur
    Shimano Deore LinkGlide, 10-speed
  • Brakes
    Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
  • Brake Levers
    Tektro HD-M745 Orion
  • Cassette
    Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
  • Chain
    Shimano, LinkGlide, CN-LG500
  • Crankset
    FSA Comet E-Bike crank arm set FSA MegaTooth Direct-mount 1X steel 36T
  • Bottom Bracket
    N/A
  • Rims
    Giant AM 29"
  • Hubs
    Giant eTracker Boost, [F] 110x15 [R] 148x12mm
  • Spokes
    Stainless Steel
  • Tires
    Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO, 60TPI [F] Maxxis Dissector 29X2.40" WT Foldable, TLR, EXO, 60TPI [R]
  • Extras
    -
  • Lighting
    -
  • Lock
    Torx 25 Battery Lock with built-in Torque limiter
  • Carrier
    -
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Download PDF

Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products with your local retailer at the time of sale if purchasing in-store. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs.

Geometry

Geometry


Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.




  • S
      163 cm to 172 cm
  • M
      171 cm to 180 cm
  • L
      179 cm to 188 cm
  • XL
      187 cm to 198 cm
bike diagram with measurements referenced in table that follows



    S M L XL
A Seat Tube Length (mm) 400 425 450 475
B Seat Tube Angle (degrees) 76.0° 76.0° 76.0° 76.0°
C Top Tube Length (mm) 580 607 639 671
D Head Tube Length (mm) 105 115 125 135
E Head Tube Angle (degrees) 65.5° 65.5° 65.5° 65.5°
F Fork Rake (mm) 44 44 44 44
G Trail (mm) 124 124 124 124
H Wheelbase (mm) 1204 1233 1267 1301
I Chain Stay Length (mm) 468 468 468 468
J Bottom Bracket Drop (mm) 40 40 40 40
K Stack (mm) 618 627 636 646
L Reach (mm) 425 450 480 510
M Stand Over Height (mm) 760 760 780 796
O Stem Length (mm) 40 40 50 50
P Crank Length (mm) 165 165 165 165
Q Wheel Size 29" 29" 29" 29"
