REIGN E+ 2 2024

R129,990.00 RRP
Clear All

Features

Features


Every trail, every steep climb, every thrilling descent. Nothing is out of bounds with the Reign E+. This proven trail ripper gives you the power to enjoy the best parts of the ride again and again.

Key Performance Factors

Trail technology

Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor boost your capabilities on steep climbs and rugged descents. Progressive geometry with a shorter rear end and longer reach allow superior handling and agility on technic

Total control

RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.

Long-lasting power

Climb steep mountains and enjoy ripping descents all day long with the new downtube-integrated EnergyPak battery system featuring 800Wh of capacity.

Specification

Specification


Specs
  • Motor
    SyncDrive Pro 2, 85Nm, powered by Yamaha
  • Controller
    RideControl Ergo 3, grip integrated
  • Display
    RideControl GO, frame integrated LED display ANT+ Wireless display compatible
  • Battery
    EnergyPak Smart 800Wh EnergyPak Plus range extender compatible
  • Charger
    EnergyPak 6A smart charger
  • Sizes
    S, M, L, XL
  • Colours
    Sangria
  • Frame
    ALUXX SL-grade Aluminium, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, flip chip, UDH hanger 12x148mm thru-axle
  • Fork
    Fox 38 Rhythm E-Tuned, 170mm travel, 44mm offset, GRIP damper, Boost Kabolt-X 110x15mm
  • Shock
    Fox Float X Performance, EVOL Large Volume sleeve, custom tuned
  • Handlebar
    Giant Contact Trail, 35mm
  • Grips
    Giant Tactal Pro-E, single lock-on
  • Stem
    Giant Contact SL 35mm S:40mm, M:40mm, L:40mm, XL:50mm
  • Seatpost
    Giant Contact Switch, dropper, 30,9mm (S:125/M:150/L:170/XL:200)
  • Saddle
    Velo VL3594
  • Pedals
    Platform
  • Shifters
    Shimano CUES, SL-6000, 1x11
  • Front Derailleur
    MRP 1X HD2 custom co-molded chain guide
  • Rear Derailleur
    Shimano CUES, U6000, Shadow+
  • Brakes
    Shimano Deore, BR-M6120, 4-piston, hydraulic disc, 220mm[F], 203mm [R]
  • Brake Levers
    Shimano Deore BL-M6100 , I-spec EV
  • Cassette
    Shimano Cues LinkGlide, CS-LG400-11, 11-50T, 11-speed
  • Chain
    Shimano LinkGlide, CN-LG500
  • Crankset
    Praxis Wave™ 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set S:160mm, M: 160mm, L:165mm, XL:165mm
  • Bottom Bracket
    N/A
  • Rims
    Giant AM 29" [F] 27.5" [R], Tubeless ready
  • Hubs
    Shimano MT410 Boost, Center-Lock
  • Spokes
    Sapim E-Lite [R] Race [F], e-bike optimised
  • Tires
    Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra [F] Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
  • Extras
    Tubeless kit (liquid, valves, levers, manual, tool)
  • Lock
    Torx 25 Battery Lock with built-in Torque limiter
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Download PDF

Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products with your local retailer at the time of sale if purchasing in-store. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs.

Geometry

Geometry


Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

bike diagram with measurements referenced in table that follows

    S M L XL
    LOW | HIGH LOW | HIGH LOW | HIGH LOW | HIGH
A Seat Tube Length (mm) 400 425 450 475
A1 SeatpostInsertionDepth (mm) 230 260 280 310
B Seat Tube Angle (degrees) 76.7° | 77.5° 76.7° | 77.5° 76.7° | 77.5° 76.7° | 77.5°
C Top Tube Length (mm) 569 | 568 595 | 594 622 | 621 649 | 648
D Head Tube Length (mm) 100 100 110 120
E Head Tube Angle (degrees) 63.7° | 64.5° 63.7° | 64.5° 63.7° | 64.5° 63.7° | 64.5°
F Fork Rake (mm) 44 44 44 44
G Trail (mm) 135.5 | 132.1 135 | 132 135 | 132 135.5 | 132.1
H Wheelbase (mm) 1209 | 1210 1236 | 1237 1265 | 1266 1295 | 1296
I Chain Stay Length (mm) 457 | 455 454 | 454 454 | 454 454 | 454
J Bottom Bracket Drop (mm) 25 | 15 25 | 15 25 | 15 25 | 15
K Stack (mm) 636 | 632 635 | 632 645 | 641 654 | 650
L Reach (mm) 425 | 430 450 | 455 475 | 480 500 | 505
M Stand Over Height (mm) 785 | 789 772 | 776 771 | 775 768 | 772
O Stem Length (mm) 40 40 40 50
P Crank Length (mm) 160 160 165 165
Q Wheel Size [F] 29" [R] 27.5" [F] 29" [R] 27.5" [F] 29" [R] 27.5" [F] 29" [R] 27.5"
